Major Objective:

To develop mesh(hex, shell) models of various engine components

Inputs :

• Geometry information

  Connections and material data

  Load case information

  Test results for correlation work

Scope/Task :

• Mesh construction for given CAD data

  Quality check as per guidelines

  Assign property & Material from received date

  Integrating components in sub assembly level - Contact, Bolt, weld, etc.

  Loads and Boundary conditions

  Simulate FE model

Deliverables :

• Meshing of the component / assembly as per inputs with

  Property & material assignment

  Assembly connections

  Contacts

  Load and boundary conditions

  Assumptions and engineering decisions report (if any)
