SCOPE OF WORK

• Concept development

  Fixation concepts

  Tooling feasibility

  DFA/ DFM work

  DMU Check

CAD Tool:

• CATIA V5

Project Description:

• Development of concept data from the strak

  Design of glove box along with mechanism.

  Designing of ducts along with connector parts.

  DMU analysis to check clearances with environment data

  Checking all the data for tooling feasibility

Input:

• Strak


  Environment/ Background data


  Attachment schemes


  Mould Direction


  Material

Challenges :

• Design of leather variant for Cockpit Upper as their area some critical areas for tooling for sliders.

  Maintain consistent cross-sectional area in defrost air channel to ensure uniform airflow and avoid pressure drop.

  Glovebox locking fixations.

  Fixations for ambient light with main carrier

Project Description:

• Design of Cockpit Verkleidng and footwell covers for proto and serial phase.

Challenges :

• Tooling for verkleidung as there are more sliders and need to check space for slider movements.

  Alignment of speaker and diagnosis connector positions for footwell cover.

Project Description:

• Design of Cockpit parts for proto and serial phase with fixations and tool feasibility along with concepts.

  Design of slush moulded part

  DMU check with environment

Challenges :

• Design of carrier for slush molding part by considering sealing areas for foam injection.

  To design common, defrost channel for leather and slush variants.

  Defining of glove box opening angle
